menger3d

$generating a menger fractal with python for maya$

$To generate this fractal, python classes were written to subdivide pairs of points into an arbitrary recursive depth based on arbitrary dimensions for the "menger sponge." Going further I rewrote the base class (credit to Sasha Ouellet for most of that) for greater flexibility in altering the shape and methods of division. In generating the ASS file for Arnold 5 for Maya, I exported an example "StandIn" of just a single cube and used that information to write out a whole bunch of cubes for the Menger Sponge.$

class Menger3D():
	def __init__(self, sideLength, depth, toRemove=[4],freq=4.0,amp=0.2):
		self.sideLength = sideLength
		self.depth = depth
		self.freq = freq
		self.amp = amp
		self.toRemove = toRemove
		self.cubes = []
		self.deleted = []

		self.mengerDivide(Cube([1.0,1.0,1.0], self.sideLength), self.depth)
		self.getPoints()
		self.distort()
		self.getBounds(distorted = True)

	def mengerDivide(self,cube,depth):
		if depth == 0:
			self.cubes.append(cube)
			return

		divided = cube.divide()
		kept = []

		for i, cube in enumerate(divided):
			if i in self.toRemove:
				self.deleted.append(cube)
			else:
				kept.append(cube)

		for cb in kept:
			self.mengerDivide(cb, depth - 1)

	def everyOther(self,index=[1]):
		return self.cubes[1::2]

	def getPoints(self, inverse = False):
		if inverse:
			cubes = self.deleted
		else:
			cubes = self.cubes
		self.pnts = []
		for cube in self.cubes:
			self.pnts.append(cube.center)
		return self.pnts

	def sortBy(self,param=[0]):
		self.pnts.sort(key = lambda x: x[0])
		return self.pnts

	def distort(self):
		self.newData = self.sortBy()
		for pnt in self.newData:
			pnt[1] -= self.amp*math.cos(self.freq*pnt[0])
		return self.newData

	def getBounds(self, distorted = False):
		if distorted:
			pnts = self.newData
		else:
			pnts = self.pnts

		minx = min(pnts, key=lambda x: x[0])
		miny = min(pnts, key=lambda x: x[1])
		minz = min(pnts, key=lambda x: x[2])
		maxx = max(pnts, key=lambda x: x[0])
		maxy = max(pnts, key=lambda x: x[1])
		maxz = max(pnts, key=lambda x: x[2])

		self.bounds = [minx[0], miny[1], minz[2], maxx[0], maxy[1], maxz[2]]
		return self.bounds

$Here is the main recursive dividing class of the menger fractal. It constructs the menger by calling the Cube class recursively. There are extra functions for sorting the points by position, distorting them with a sine curve, and getting the bounding box.$

from cube import Menger3D
from ass_header import cube_info
import time
import random
import math

class MengerAss(Menger3D):
	def __init__(self, sideLength, depth, path, toRemove=[4]):
		Menger3D.__init__(self, sideLength, depth,toRemove)
		self.asspath = path

	def write(self):
		now = time.strftime("%Y %m %d %H:%M")
		num_pnts = len(self.cubes)/2

		f = open(self.asspath, 'w')
		f.write('### exported: %s\n' %(now))
		f.write('### user: jkengl20\n')
		f.write('### bounds: {} {} {} {} {} {} \n'.format(*self.bounds))
		f.write('### fps: 24.000000\n### render_layer: defaultRenderLayer\n### frame: 1.000000\n')

		count = 0
		for cube in self.cubes:
			f.write('polymesh\n{\n name pCubeShape%i \n' % count)
			f.write(' visibility 255\n sidedness 255\n receive_shadows on\n self_shadows on\n matrix\n')
			#side lengths
			f.write(' %f 0 0 0\n 0 %f 0 0\n 0 0 %f 0\n' % (cube.sideLength,cube.sideLength,cube.sideLength))
			#positions
			f.write(' %f %f %f 1\n' % (cube.center[0],cube.center[1],cube.center[2]))
			f.write(' opaque on\n matte off\n id %i' % (141609554 + count))
			f.write('%s' % cube_info)
			f.write('} \n')
			count += 1
		f.close()

if __name__ == '__main__':

	#toRemove = [4,10,12,13,14,16,22]
	toRemove = [6,8,12,16,18,31,33,37,41,43,56,58,62,66,68,81,83,87,91,93,106,108,112,116,118,52,26,28,76,78,34,44,64,84,94,46,48,72,96,98,30,40,60,80,90]
	m1 = MengerAss(1.0,2, 'D:/scad/vsfx/tech312/312/test3d.ass', toRemove)

	m1.write()




